BMS adopts three-level management architecture, supporting real-time data collection, status monitoring, control and protection,
The system is designed with comprehensive software and hardware protection functions, UL certified with high safety and reliability
Excellent equipment compatibility and EMC anti-interference performance, equipped with abundant communication interfaces
| electrochemical system | LFP | Rated voltage | 512 Vdc |
| Rated capacity | 120Ah | Rated energy | 61.44 kWh |
| Number of battery modules | 10（max:12） | Number of HV box | 1 |
| Voltage range | 432~568 Vdc | Maxmium operating ambient temperature | Charging 0℃-40℃ Discharge -20℃-40℃ |
| Recommended operating ambient temperature | 15℃-35℃ | Maximum discharge power | 300 kW |
| Battery module type | 51.2V120Ah (2P16S) | storage temperature | -20-45℃ |
| Dimension | 600×850×2000mm | Weight | 884kg |
| Protection grade | IP20 |
