| Parameters | Vacuum Circuit Breaker | Isolating / Earthing Switch | ||
| Rated voltage | 40.5 kV(Dry air) | 40.5 kV(Dry air) | ||
| Power frequency withstand voltage | 95/118 kV | 95/118 kV | ||
| Impulse withstand voltage | 185/215 kV | 185/215 kV | ||
| Rated current | 1250 A | 1250 A | ||
| Rated short circuit breaking current | 31.5 kA | |||
| Rated short circuit making current | 80 kA | 80 kA | ||
| Rated short time withstand current | 31.5/4 kA | 31.5 kA | ||
| Mechanical life | Circuit breaker 10000 times | Isolating 5000 times / Earthing 5000 times | ||
36-40.5kV Eco-friendly Dead Tank Gas Insulated Switchgear shall comply with GB/T11022-2020,GB3906-2020,GB1984-2024,GB1985-2023,IEC62271-1,IEC62271-102,IEC62271-200,IEC62271-100,IEC 60255 and other standards.
